Y Konnektör Murr 13880
Konnektör
Y Konnektör
Murr
Murr Y Konnektör
Murr 13880
Murr 7000-41131-0000000
Açıklama
Murr 13880 7000-41131-0000000 Y Konnektör
Murr Y Konnektör 7000-41131-0000000
T-COUPLER SLIMLINE M12 MALE / 2X M12 FEMALE
Art.No.: 7000-41131-0000000
Alternative product: 7000-41121-0000000
Technical Data
T-coupler (Slim Line)
Male straight – female straight
M12 – M12, 5-pole
Distribution function (NO)
Plastic housings with good resistance against chemicals and oils. The resistance to aggressive media should be individually tested for your application. Further details on request.
| Operating voltage | max. 60 V AC/DC |
| Operating current per contact | max. 4 A |
| Locking of ports | Screw thread M12 × 1 mm (recommended torque 0.6 Nm) self-securing |
| Protection | IP67 inserted and tightened (EN 60529) |
| Locking material | Zinc die casting, matte nickel plated |
| Rated surge voltage | 1.5 kV |
General data
| Temperature range | -25…+85 °C |
